Product Description:
| Layout | 75% Layout, US QWERTY |
|---|---|
| Number of Keys | 82 Keys |
| Battery | No Battery |
| Connectivity | Wired Only (USB A to USB C) |
| Front Height | 2.2cm |
| Typing Angle | 6, 8.5 and 11.5 degree |
| Case Material | Plastic |
| Plate Material | FR4 Plate |
| Flex-Cut | No Flex-Cut |
| Stabilizers | Plate-Mount Stabilizer |
| Mounting Structure | Gasket-Mount |
| Sound Dampening | 4 Layers of Paddings, including Latex Sandwich Foam, IXPE Switch Pad, Bottom Silicone and Bottom Foam |
| Keycaps Profile | Cherry Profile |
| Keycaps Material | PBT Keycap and Extra PC Transparent Keycap |
| Keycaps Manufacturing Technique | Double-Shot |
| Hot Swappable | Yes, with other south-facing magnetic switch |
| RGB | Yes, per-key south-facing RGB backlight |
| Polling Rate | 8000hz polling in wired mode |
| Scan Rate | 32,000 scanning and 128,000 per-key scanning |
| Latency | 0.125ms |
| Anti-Ghosting | Yes, HE80 supports N-Key Rollover |
| Compatibility | Mac/WIN/Android/Linux/PS4/PS5/Switch |
| Keyboard Dimensions | 33.2*14.6*4.2cm |
| Keyboard Weight | 0.83kg |
| Switch Specifications | Switch Name: EPOMAKER MagneX Switch Switch Type: Magnetic Hall Effect Switch Initial Force: 30gf Min Trigger Force: 37±5gf Bottom-out Force: 45gf Max Trigger Travel: Adjustable per 0.02mm in EPOMAKER Web Driver Total Travel: 3.4±0.1mm Initial Magnetic Flux (if PCB is 1.6mm thick): 90±10Gs End Magnetic Flux (if PCB is 1.6mm thick): 550±55Gs Material of Top Cover: PC Material of Bottom Base: PC Material of Stem: POM Spring Length: 18mm Lubed or Not: Lubed in Factory Life spans: 1,000,000,000 |
| Downloads | Epomaker HE80 Driver Epomaker HE80 Manual |
| Inside the Box | 1* HE80 Wired Magnetic Hall Effect Gaming Keyboard 1* Multilingual Manual (EN, ES, FR, IT, KR, JP, CN) 3* Extra Magnetic Switch 3* Additional PBT Keycaps 1* 2-in-1 Keycap-and-Switch Puller |
