| Layout |
65% ANSI US Layout |
| Number of Keys |
68 keys |
| Battery |
No Battery |
| Connectivity |
Cable Wired (USB A to USB C) |
| Switch Between Mac and WIN |
No physical switch, and HE68 Lite automatically switch to the correct OS mode. |
| Case Material |
ABS Plastic |
| Plate Material |
PC Plastic |
| Flex-Cut |
No Flex-Cut |
| Stabilizers |
Plate-Mount Stabilizer |
| Mounting Structure |
Tray-Mount |
| PCB Thickness |
1.6mm |
| Sound Dampening |
PRO Sandwich Foam, IXPE Switch Pad, PET Sound-Enhancement Pad, Switch Socket Pad, Bottom Foam |
| Keycaps Profile |
Cherry Profile |
| Keycaps Material |
PBT Plastic |
| Keycaps Manufacturing Technique |
Double-Shot |
| Switch |
Hall Effect Switch |
| RGB |
A-RGB Technic, South-facing, per-key RGB |
| Polling Rate |
8000Hz |
| Scan Rate |
128Khz |
| Latency |
0.125ms |
| Adjustable Travel |
0.1mm to 3.4mm, per 0.01mm |
| SOCD (Snap Key) |
Yes, the HE68 Lite Keyboard supports SOCD. |
| DKS & MT |
Yes, the HE68 Lite Keyboard supports dynamic keystroke and mod tap function. |
| Dead-Zone |
HE68 Lite keyboard supports zero dead-zones, and the dead zone is adjustable between 0 to 1mm in the software. |
| Programmable |
Yes, the HE68 Lite keyboard comes with software for Windows and Mac. |
| Anti-Ghosting |
Yes, the HE68 Lite keyboard supports N-Key Rollover. |
| Compatibility |
Mac/WIN/Android |
| Keyboard Dimensions |
32.2cm in Length, 12cm in Width, 4cm in Height. |
| Keyboard Weight |
0.65kg |
| Switch Specifications |
- Switch Name: Epomaker Clear Mag Switch
- Switch Type: Magnetic Hall Effect Switch
- Initial Force: 25gf Min
- Trigger Force: 37±5gf
- Bottom-out Force: 45gf Max
- Trigger Travel: Adjustable in EPOMAKER Software from 0.1mm to 3.4mm, per 0.01mm
- Total Travel: 3.4±0.1mm
- Initial Magnetic Flux (if PCB is 1.6mm thick): 90±10Gs
- End Magnetic Flux (if PCB is 1.6mm thick): 550±50Gs
- Stem Material: Green POM
- Top Material: Transparent PC
- Bottom Base Material: Green PA
- Lubed or Not: Lubed in Factory
- Spring Length: 18mm
- Life Spans: 1,000,000,000
|
